High-Performance Composite Filaments

Fiberonโ„ข PA6-CF20

Exceptional stiffness, strength, heat resistance up to 215ยฐC, with superior layer adhesion

Shop now
HDT(ยฐC)
0.45Mpa215
Young's
Modulus
Dry8636 MPa
Young's
Modulus
Wet2508 MPa
Spool info:
1.75mm
500g, 2kg

About PA6-CF20

TDSSDS

Fiberonโ„ข PA6-CF20 is a 20% carbon fiber reinforced Nylon 6 filament. The carbon fiber reinforcement provides significantly improved stiffness, strength and heat resistance with outstanding layer adhesion thanks to Fiber Adhesionโ„ข Technology. PA6-CF outperforms almost every 3D printing material, offering extreme durability and functionality while featuring a heat deflection temperature of 215ยฐC.

Application Category

Automotive
Composite Manufacturing
Industrial parts
Heat deflection temperature (0.45Mpa)
HDT(ยฐC)215
Young's modulus
Dry8636 MPa
Wet2508 MPa
Tensile strength
dry (x-y)
109.3 MPa
dry (z)
54.0 MPa
wet (x-y)
54.7 Mpa
wet (z)
25.5 MPa
Charpy Impact strength
notched
dry
11.0 kJ/mยฒ
wet
35.6 kJ/mยฒ
Bending modulus
dry (x-y)
7037.6 MPa
wet (x-y)
2286.2 Mpa
(*) all data are from printed specimen
High heat deflection temperature
Excellent isotropic rigidity

Download a printer profile

Printer compatibility

Printing temperature:
280-300ยฐC
Bed temperature:
40-50ยฐC

(*) No heated chamber or enclosure needed

Nozzle compatibility

Using a wear-resistant nozzle, such as hardened steel or ruby nozzle, is highly recommended when printing
PA6-CF20
The best thing on the marker for your next awesome project
Shop now

Get inspired by our featured case studies

Our goal is to make materials with a key characteristic - advanced materials that are easy to use for anyone, coming from any industry, without the need of an advanced technological skill set.
June 12, 2024
Recreating Conditions at the Centre of Planets
Read More
September 10, 2023
Polymaker & Amesos: Water Pump Mounting Plates for Agricultural Drones
Read More
Not sure?
Chat with a specialist
Contact us now
Check material comparison guide
  • What is the percentage of the carbon fiber content in Fiberonโ„ข PA6-CF20?

    It contains 20 wt% carbon fibers.

  • Do PA6-CF20 prints need annealing? What are the annealing conditions?

    We strongly recommend 100ยฐC, 10h annealing to achieve the best performance of the material.
