Fiberonโข PA612-CF15
Exceptional mechanical strength, heat resistance, and dimensional stability
0.45Mpa175
Modulus
Dry5136 MPa
Modulus
Wet3990 MPa
About PA612-CF15
Fiberonโข PA612-CF15 is a carbon fiber reinforced polyamide filament based on a copolymer of PA6 and PA12. Thanks to its chemical structure, this product has lower moisture sensitivity compared to PA6/66 and PA6-based materials, and better mechanical properties than PA12-based materials. In addition, the carbon fiber reinforcement and Warp-free technology enhance the dimensional stability of the prints produced with this material.
Application Category
notched
Printer compatibility
250-300ยฐC
Bed temperature:
40-50ยฐC
(*) No heated chamber or enclosure needed
Nozzle compatibility
Get inspired by our featured case studies
Our goal is to make materials with a key characteristic - advanced materials that are easy to use for anyone, coming from any industry, without the need of an advanced technological skill set.Chat with a specialist
What is the difference between Fiberonโข PA612-CF15 and Fiberonโข PA6-CF20 ?
Fiberonโข PA612-CF15 exhibits enhanced rigidity and strength in wet conditions compared to Fiberonโข PA6-CF20, owing to its longer chemical chain. While both materials do absorb moisture, PA612-CF demonstrates minimal reduction in mechanical properties, resulting in superior overall performance in wet environments when compared to PA6-CF.
Is it safe while putting cardboard spool to dry the Fiberonโข PA612-CF15 in the oven?
Yes, we have ensured the dimensional stability of the cardboard by subjecting it to a temperature of 100ยฐร in the oven. This meticulous drying process guarantees that the cardboard remains free from warping and distortion.
What is the percentage of the carbon fiber content in Fiberonโข PA612-CF15?
It contains 15 wt% carbon fibers.
Do PA612-CF15 prints need annealing? What are the annealing conditions?
We strongly recommend 100ยฐC, 10h annealing to achieve the best performance of the material.
